הַחכָּרָה Demag AC220-5 Dutch Registration, 10x6x10, 220t Ca

Motor Kran: -

Gegengewicht: 70200 kg

This Demag AC220-5 can be sold with warranty. Inform about our conditions! The Sterk Contra weight trailer is included, along with a mover equipped with a remote control (See Pictures) Manufacturer: Demag Typ: AC220-5 Manufacturer Year: 2020 Fuel: Diesel Chassis number: WMGKB5176LZVF0609 Serial number: 82609 KM: 62.585 Working Hours: 5.422 h Max. lifting capacity: 220 tons Main boom: 12.8 m – 78 m Engine: Scania DC13, Euromot 4 / Tier 4F compliant Power: 368 kW (500 HP) @ 2100 rpm Torque: 2373 Nm @ 1300 rpm Drive Configuration: 10x6x10 Transmission: ZF AS-Tronic 12-speed automated gearbox with 2 reverse gears Hydraulic retarder & off-road gear Dimensions Overall Length (with boom): Approx. 15.33 m Overall Width: 3.00 m Overall Height (transport position): 4.00 m Wheelbase: Approx. 3 x 1.65 m + 2.10 m Turning Radius (inner): Approx. 8.4 m Max. Outrigger Base: 8.4 m x 8.9 m Outrigger Positions: 2.75 m / 5.54 m / 7.0 m / 8.4 m Stability & Smart Control Outriggers: 4-point H-type fully hydraulic outriggers Base widths: 2.75 m, 5.54 m, 7.0 m, and 8.4 m IC-1 Plus Control System: Enables asymmetrical outrigger positioning Real-time load chart adaptation Outrigger Monitoring: Horizontal beam stroke monitored with warning system. Jib Extensions: 21 m folding swing-away jib with manual offset angles (20°/40°) Lubrication: Central lubrication system for both carrier and superstructure (e.g., luffing cylinders, slewing ring) Infotainment: Radios in both cabs with CD, USB, Aux-In and Bluetooth Heating & Cooling: Carrier Cab Heating: 12 kW warm water Superstructure Heating: 5 kW independent Carrier Air Conditioning: 7 kW Superstructure A/C: 5 kW Superstructure Cab Infinitely tiltable up to 16°, sliding windows, front window folds out, extendable pedestals. Counterweight System Standard Counterweight: 51.6 tonnes Maximum Counterweight: 70.2 tonnes Automatic Rigging System: For quick and safe counterweight setup. Fall Protection: Counterweight fall arrest system included (compliant with NL regulations). Dutch vehicle registration Crane Logbook All necessary documents and papers. CE (Declaration of Conformity). More detailed pictures / product movie on our website. pfeifermachinery.com Above specifications are subject to change without prior notice and subject to errors.
